V1000
Compact Vector Control Drives
V1000
Compact Vector Control Drives
The V1000 is a world-class compact current vector drive that defines a new world standard. Demands for efficient production and better maintainability are on the rise, spurred by global competition. Yaskawa pays off the promise of being in control with products that make businesses move. The optimum balance of energy input, product output, maintenance risk, and long life is reached with Yaskawa. The V1000 provides a world of power in the palm of your hand!
Ratings:
- 1 Phase 200VAC, 0.2kW to 5.5kW
- 3 Phase 200VAC, 0.2kW to 18.5kW
- 3 Phase 400VAC, 0.4kW to 18.5kW
up to 30% smaller than the competition
Current vector control, open loop.
RoHS compliance
On-line tuning.
Induction motor (IM) or permanent magnet motor (PM) operation.
Function Block Diagram (FBD) programming via DriveWorksEZ™.
Side-by-side installation due to patented hybrid heatsink.
Removable terminal block with parameter backup function.
Common programming with all other Yaskawa drives
DriveWizard software available at no extra cost.
One-touch copy function with verify.
Super-fast 2 ms scan cycle with dual CPU.
EN954-1 Safety Cat. 3, Stop Cat. 0
Increased vibration resistance, from 20 Hz to 50 Hz (0.65G).
1 in 10,000 failure rate.
Swing PWM function to decrease noise at low carrier frequencies.
Pre-maintenance function.
Modbus communication
Cooling fan replacement without tools.
MTBF: 28 years Short Circuit Current Rating (SCCR): 30kA rms symmetrical.
Heavy Duty Application
- Compressor
- Chain block Hoist
- Auto shutter
- Conveyor
- Food & Beverage Industry
- Packaging
- Commercial Washing Machine And Many more
Normal Duty Application
- HVAC
- Fan
- Pump and Many more
